美規UL498插頭插座量規

美國UL498量規， Articulate probe with web stop

， Probe

， Flat probe， Reference plug(模擬插頭)

， Typical test apparatus (模擬插頭拉力裝置)

， Improper insertion test blades，防誤插入測試片

， Test plug

， Test blade， Receptacle test fixture

， Push out tool

， Bridge， Test pin A

， Test pin B

， 57g ground pin， 113g ground pin

， No.14AWG test pin

，

型號： SC-U8
品牌：廣州世測（SHC)
技術標準： UL498 Attachment Plugs Receptacles

量規名稱：UL498插頭插座量規

量規規格：UL498 figure91-1742

量規參數：110V，15A

量規型號：SC-UL91-1742

量規標準：符合UL498Attachment Plugs and Receptacles 要求;

美式UL量規較多

，請聯系我們

，獲取清單和詳細資料。

產品用途

用來檢驗和檢查UL498標準系列下的插頭插座結構尺寸

。

產品特征

---量規的尺寸，公差

，材料

，硬度，表面粗糙度應符合標準的要求

---表面耐腐蝕和耐磨損，能抵擋在正常使用過程中可能出現的接觸性腐蝕（操作者手表面可能存在汗液

，其腐蝕效果相當于NACL鹽溶液或NH₄CL鹽溶液的腐蝕）而不起銹斑

---材料的硬度達到洛氏硬度58以上

---材料的保熱膨脹系數小

，尺寸及公差穩定可靠

―每個量規能提供校準證書

符合標準

UL498

UL498量規列表：

序號	量規名稱	標準圖號 (舊版本)	標準圖號 (2012版)	標準圖號 (2019版)	世測型號
1	Articulate probe with web stop UL試驗指	Figure 9.1	Figure 9.1	Figure 9.1	SC-UL91
2	Probe	Figure 10.1	Figure 10.1	Figure 10.1	SC-UL101
3	Flat probe	Figure 31.1	Figure 31.1	Figure 31.1	SC- UL311
4	Reference plug(模擬插頭)	Figure 69.1	Figure 73.1	Figure 74.1	SC- UL741
5	Typical test apparatus (模擬插頭拉力裝置)	Figure 69.2	Figure 73.2	Figure 74.1	SC- UL741
6	Improper insertion test blades- test blade1 防誤插入測試片	Figure 94.1	Figure 98.1	Figure 100.1	SC- UL1001
6	Improper insertion test blades- test blade2 防誤插入測試片	Figure 94.1	Figure 98.1	Figure 100.1	SC- UL1001
7	Test gauge	Figure 105.1	Figure 109.1	Figure 111.1	SC- UL1111
8	15lb Test Fixture (SU3384)			Figure 111.1A	SC- UL111A
9	Test blade	Figure 105.2	Figure 109.2	Figure 111.2	SC- UL1112
10	Receptacle test fixture	Figure 118.1	Figure 122.1	Figure 124.1	SC- UL1241
11	Pushout Tool	Figure 118.3	Figure 122.3	Figure 124.3	SC- UL1243
12	Bridge	Figure 118.5	Figure 122.5	Figure 124.5	SC- UL1245
13	Test pin A	Figure 119.1	Figure 123.1	Figure 125.1	SC- UL1251
14	Test pin B	Figure 119.2	Figure 123.2	Figure 125.2	SC- UL1252
15	2oz(57g) ground pin	Figure 119.3	Figure 123.3	Figure 125.3	SC- UL1253
16	4oz (113g) ground pin	Figure 119.4	Figure 123.4	Figure 125.4	SC- UL1254
17	14AWG Test Pin	Figure 129.2	Figure 133.2	Figure 136.2	SC- UL1362
18	Small test probe	Figure 132.1	Figure 136.1	Figure 139.1	SC- UL1391
19	Large test probe	Figure 132.2	Figure 136.2	Figure 139.2	SC- UL1392
20	Fixture for assembly security test	Figure 144.2	Figure 165.2	Figure 174.2	SC- UL1742
21	Standardgroundingpin	Figure SD 5.1	Figure SD 5.1	Figure SC5.1	SC- ULSC51
22	Standardgroundingpin	Figure SD 13.1	Figure SD 13.1	Figure SC 13.1	SC- ULSC131
23	Oversize grounding pin	Figure SD 13.2	Figure SD 13.2	Figure SC 13.2	SC- ULSC132
24	Standardgroundingpin			Figure SC 21.1	SC- ULSC211
25	Oversize grounding pin			Figure SC 25.1	SC- ULSC251
